| Specifications | Installation | |
| Color:
Black Length: 4 foot (others available upon special order) Sensitivity: nominal 4 psi Lead Wire: SJTO, 18 gauge, 10 ft. length Wire Outlet Location: specify universal, right, or left side Electrical Requirements: 24 volt AC or DC, ½ amp Electrical Diagram: 2 wire N.O. configuration Contact Element: Alumaglas® Materials: Base = rigid extruded PVC; Cover = flexible PVC Temperature Range: -30ºF to +155ºF |
The MGR20
and MGS20 were designed to minimize installation time while offering
customers the three-sided protection for the leading edge of the gate.
These edge sensors simply clip on to the 2: frame. The rigid base
extends beyond the sensitized portion of the edge sensor to form mounting
flanges. To mount, drill 1/8" holes through the mounting flanges and
into the gate frame every 24". Permanently attach with #10 screws.
Run wire to the gate operator installation manual. Test the edge sensor
and inform the property owner of their obligation to regularly test.
When properly maintained, the MGR20 and MGS20 offer years of trouble
free service. Note: For safe operation, use maximum 24 volt AC or DC power. For detailed instructions, contact MillerEdge, Inc. |
